XSA1000TG Series LOW Phase No Spectrum Analyzer

+ Nruab Nrab Ntawm 9 kHz mus txog 3.6 GHz + 150dBm Cov Zaub Teeb Zis Qib + Qib Qis-82dBc / Hz @ 1Gz thiab offset ntawm 10KHz + Tag Nrho Amplitude Txoj Cai <1.5db +="" 10hz="" minimum="" resolution="" bandwidth="" (rbw)="" +="" emi="" pre-compliance="" test="" khoom="" siv="" +="" 1.5="" ghz="" nrhiav="" tshuab="" generator="" +="" 10.4="" nti="" zaub="">

Xa kev nug

Tsham tam sim no

Khoom Taw qhia

+ Zaus ntau ntawm 9 kHz mus txog 3.6 GHz
+ 150dBm Zaub Yim Nruab Nrab Qis Qis
+ Theem Quav-82dBc / Hz @ 1Gz thiab offset ntawm 10KHz
+ Tag nrho Amplitude Accuracy <>
+ 10Hz Minimum Resolution Bandwidth (RBW)
+ EMI Cov Khoom Siv Ua Ntej Ua Ntej Ua Ntej
+ 1.5 GHz Mus Saib Cov Khoom Siv Generator
+ 10.4 nti zaub

Qauv	Ntau Zaus	RBW	Theem Quav (Hom Lag Luam)	TG qauv
XSA1015	9kHz - 1.5GHz	10Hz - 3MHz	<-80dbc hz="" @="" 1="">	√
XSA1036	9kHz - 3.6GHz	10Hz - 3MHz	<-90 dbc="" hz="" @="" 30="" khz="">	√

Qis suab: <- 80="" dbc="" hz="" @="" 1="" ghz="" @="" 30="" khz="">

Cov theem zoo nkauj nrov suab paj nruag - <-80dbc hz="" @="" 30khz="" enables="" cov="" neeg="" siv="" kev="" ntsuam="" xyuas="" cov="" kws="" tshaj="" lij="" thiab="" cov="" teeb="" tsa="" hluav="" taws="">

FAQ

Yam dab tsi cuam tshuam cov hwj huam pab me me?

Nrog rau kev thov kev hloov khoom siv fais fab khoom nyob rau hauv kev ua lag luam, nce me dua, sib zog, high-efficiency, qis hluav taws xob, qis dua thiab lwm yam ntxwv yuav tsum ua kom txaus siab ntau yam khoom hluav taws xob. Yuav kom ua tau raws li cov cuab yeej siv khoom hluav taws xob hauv cav, tam siv cov khoom fais fab yuav tsum tau ua me me. Vim nws lub cev nyhav, nws tau los ua qhov teeb meem ntawm kev tsim kev txhawj xeeb rau cov neeg tsim khoom kom muaj kev khiav hauj lwm ntau zaus ntawm kev siv cov khoom siv fais fab. Txawm li cas los xij, yam dab tsi yog qhov tsis zoo ntawm kev hloov cov khoom siv fais fab? Nyob rau hauv qhov tseeb, nws tsuas yog muaj peb yam: hloov hlab, transformers, thiab EMI thiab PCB tsim.

Kev Ntaus Nqua
Qauv	XSA1015TG	XSA1036TG
Zaus
Ntau ntau	9kHz-1.5 GHz	9kHz - 3.6 GHz
Daws teeb meem	1Hz
Kev ncua sij hawm ncua
Ntau ntau	0 Hz, 100 Hz mus rau ntau zaus ntawm cov khoom
Qhov tseeb	± ncua sij hawm / (swept points)
Internal reference
Siv zaus	10.000000 MHz
Kub stability	<2.5ppm (15="" ℃="" to="" 35="">
Tus nqi laus	<1ppm>
Bandwidth
Kev daws teeb meem bandwidth (-3 dB)	10Hz mus rau 500kHz (hauv 1 txog 10 kev sib lawv liag), 1MHz, 3MHz
Video bandwidth (-3 dB)	10Hz mus rau 3MHz

Amplitude Specification
Teeb suab nrov nruab nrab (DANL)
Kev tawm tswv yim ua ntej 0 dB, 1Hz kev daws teeb meem bandwidth
Npaj tawm	1 MHz ~ 10 MHz -130dBm (nominated)
	10 MHz ~ 1 GHz -130dBm (nominated)
	1 GHz ~ 1.5 GHz -128 dBm (nominated)
Preamp on	1 MHz ~ 10 MHz -150dBm (nominated)
	10 MHz ~ 1 GHz -150dBm (nominated)
	1 GHz ~ 1.5 GHz -148 dBm (nominated)
Theem suab
20 ℃ ~ 30 ℃, fc = 1 GHz
Theem suab	<-85 dbc="" hz="" @="" 10="" khz="">
	<-100 dbc="" hz="" @="" 100="" khz="">
	<-110 dbc="" hz="" @="" 1="" mhz="">
Theem zaub ntau yam
Teev nyiaj teev ua haujlwm	1dB ~ 255dB
Tawm hauv lub cev	0 kom paub siv theem
theem tsev	dBm, dBuW, dBpW, dBmV, dBuV, W, V
Ntsiab Lus	201 ~ 1001
Cov naj npawb ntawm cov cim	5
Detectors	Zoo-peak, negative-peak, sample, qub, RMS
Lw khiav haujlwm	Cov ntawv sau tseeb, Max tuav, Min tuav, Saib, Khim, Nruab Nrab
Qhov tseeb
Kev Taw Qhia Kev Tawm Tsam Hloov Kev Tsis Taus	20 ℃ ~ 30 ℃, fc = 50 MHz, Preamplifier tawm, 20dB RF attenuation, input teeb liab 0 ~ 39 dB ± 0.5 dB
Tsis Ncaj Ncees Amplitude Tsis Muaj	20 ℃ ~ 30 ℃, fc = 50 MHz, RBW = 1 kHz, VBW = 1 kHz, ncov ntes, 20 dB RF attenuation, Preamplifier tawm ± 0.4 dB, input teeb liab = -20dBm Preamplifier Rau 0.5 dB, input teeb liab = -40dBm
Tsis paub meej	input teeb liab 0dbm ~ -50dbm
Tsis paub meej	± 1.5 dB
VSWR	input 10 dB RF attenuation, 1 MHz ~ 1.5GHz
VSWR	<1.5,>
Nrhiav cov generator
Cov zis tawm ntau zaus	100 kHz ~ 1.5 GHz
Cov zis muaj hwj chim ntau	-30 dBm ~ 0 dBm,
Tawm zis muaj peev xwm daws teeb meem	1DB
Tawm zis tso tawm	+/- 3 dB
Kev nyab xeeb siab tshaj plaws rov qab	Nruab nrab zog tag nrho: 30 dBm, DC: ± 50 VDC
Inputs thiab Outputs
Pem hauv ntej vaj huam sib luag RF input connector	50 Ω, N-poj niam
Pem hauv ntej vaj huam sib luag khiav generator tso zis	50 Ω, N-poj niam
10 M tawm tswv yim	50 Ω, N-poj niam
Qhov chaw sib txuas lus	USB Host, USB Device, LAN, earphone chaw nres nkoj, thiab VGA
Kev piav qhia dav dav dav techincal
Zaub	TFT LCD, 10.4 nti
Nyhav	5.0 kg
Dimension (W x H x D)	321 x 221 x 115 (hli)
